Air Suspension Compressor Electropneumatic Control Unit Mercedes GLE W167 GLS1673209005

Air Suspension Compressor Electropneumatic Control Unit Mercedes GLE W167 GLS 2020-2026 OE 1673209005

This is the air suspension compressor for the Mercedes-Benz GLE (W167) and GLS (X167) SUVs — the unit Mercedes calls the electropneumatic control unit, compressor and clutch in one assembly, mounted at the rear of the car. It keeps the air springs pressurised on the factory air-suspension models.

OE 1673209005 (also A1673209005) is the current number. It supersedes the earlier revisions on this platform — 1673202205, 1673208704, 1673208903, 1673209304 and 1673200404 — which is useful when a customer turns up with an older stamp on the failed unit. If it carries any of those numbers, this is the replacement they need.

Coverage runs from the GLE350 up to the GLE63, plus the GLS450/GLS580 and Maybach GLS600, model years roughly 2020 onwards. Send the VIN and the old part's number at order time — we confirm the match before dispatch, which keeps wrong-part returns off your counter. Steel-spring cars do not apply.

Q1: What are the MOQ and mixed-container options? Both are agreed per order — send your OE list and we reply with the current sheet (mixed loading across our air-suspension range is normal practice). Single units are possible for samples and test fits.

Q2: Which vehicles does OE 1663200104 cover? The W166 / X166 platform family: M-Class (W166, 2011–2015), GLE (2015–2018), GL-Class (X166, 2012–2015) and GLS (2015–2019) — all with factory front-axle air suspension.

Q3: Is this the compressor only, or the complete unit? The relay-integrated version is supplied complete: 12V, 40A, 4-pole connection, relay functions Clamp 87 and Terminal 30. Confirm which assembly your market fits when you order.

Q4: Do you offer OEM / ODM and custom packaging? Yes. We run OEM and ODM programmes for suspension compressors. Customisation services include laser LOGO engraving on the unit, colour-box printing and label printing — neutral or fully branded, agreed at order stage.

Q5: What warranty applies to wholesale accounts, and how are claims handled? 18-month warranty under normal use. Claims: notify within 48 hours of receipt with photos/video of the damage or fault — replacement is arranged per the agreed terms.

Q6: Is the dryer / service kit available as a linked SKU? Many buyers pair this air ride compressor with the dryer when refitting, since moisture is the usual cause of compressor failure. Tell us the model coverage you need and we will confirm the matching service parts.

Q7: What shipping methods and documents do you provide? Sea, air or courier by volume and destination, with export documentation. Transit times and freight quotes depend on the order size and destination port.

• OEM / ODM — supply per your specification; OE-number-matched production for brand programmes.
• Laser LOGO engraving — logo / part number lasered onto the unit.
• Colour-box printing — custom retail / trade boxes in your design.
• Label printing — barcode, OE and multilingual labels per your layout.
• Warranty — 18 months on all units under normal use.
• Documentation — export documents, OE cross-check sheets and VIN-confirmation records with every order.
