68029902AE Front Repair Kit For Jeep Grand Cherokee WK2 2011‑2021

Product Info

OE: 68029902AE

Product Name: Front Right Air Spring Repair Kit

Important Note: Only air spring bladder repair kit, without shock absorber core and damper cylinder. Front left counterpart OE: 68029903AE, non-interchangeable.

1. Product Introduction

OE Number: 68029902AE

Product Type: Air Spring Repair Kit (only rubber bladder, excluding damping shock absorber core)

Mounting Position: Front Suspension - Right Side

Structure: Multi-layer reinforced anti-aging rubber air bladder, equipped with metal pressure cover, clamping hoops and O-ring sealing kits. Designed for vehicles with intact original shock absorber cylinder and damper core. Replace the leaking air bladder independently and reuse the original shock absorber body, no need to replace the complete air strut assembly. Perfectly compatible with the original air suspension system to restore vehicle height adjustment and auto-leveling functions.

Core Advantages

• Adopts high weather-resistant composite rubber material, ozone-proof, anti-aging and temperature-resistant, adapting to complex road conditions of rain, snow and sand, effectively avoiding bladder cracking and slow air leakage.
• 1:1 OEM precision molding with identical size, telescopic stroke, interface and mounting holes, direct fit without modification for original intact shock cylinder.
• All products pass strict high-pressure air tightness test and pressure holding test before delivery, no air leakage and pressure loss, with higher stability and durability than ordinary aftermarket parts.
• Cost-effective repair solution, greatly reduce maintenance cost compared with replacing the whole air strut assembly, perfectly solve suspension air leakage and vehicle sinking failure.
• Complete with professional mounting clamps and sealing accessories, no extra parts purchase required, ready for direct installation and repair.

Solvable Common Faults

• Front right body sinking after parking
• Air suspension malfunction warning light on dashboard
• Frequent start-stop, long-term continuous operation and overheating of air compressor
• Uneven body height, driving deviation and poor cornering stability
• Aging cracks and pinhole slow air leakage on air bladder folding area
• Only air bladder leakage while shock absorber core is oil-free and intact (suitable for this repair kit)

Notice: This is a dedicated front right repair kit. Not applicable if the shock core is oil leaking, damping failed or cylinder deformed.

2. Fitment

Vehicle Model: Jeep Grand Cherokee WK2

Year Range: 2011-2016

Fitment Condition: Only for models with factory electronic air suspension system

Notes:

• Not compatible with mechanical spring suspension versions
• Front right exclusive, front left OE: 68029903AE, non-interchangeable
• Applicable only when original shock cylinder and damping core are intact
• VIN code verification is recommended before ordering to avoid wrong delivery

3. Interchangeable OE Numbers

Main OE: 68029902AE

Alternative OE: 68029902AB, 68029902AC, 68029902AD, 68029902AH, 68080194AA, 68080194AB

Remark: 68029902AE is the standard aftermarket reference OE number for Jeep Grand Cherokee WK2 front right air spring repair kit.

4. FAQ

Q1: Is 68029902AE universal for left and right? A: No. It is exclusively for the front right side. The front left replacement OE is 68029903AE. Different structure and mounting angle, non-interchangeable.

Q2: Can it fit mechanical suspension models? A: No. This kit only fits factory electronic air suspension models, not for mechanical spring versions.

Q3: When to use repair kit and when to replace full assembly? A: Choose this repair kit if only the air bladder leaks with intact shock cylinder and oil-free core. Replace the complete strut assembly if the core is oil leaking, damping failed or cylinder deformed.

Q4: Need to replace the air compressor together? A: No need if only bladder leakage and compressor works normally. Inspect or replace the compressor if it works overtime with abnormal noise and overheating to extend suspension service life.

Q5: Is professional calibration required after installation? A: Yes. Professional diagnostic equipment is required for body height calibration and system reset. Uncalibrated installation will cause height deviation and fault codes.

Q6: What is the warranty policy? A: 12-month standard warranty. Covers natural aging cracking and slow air leakage. Excludes collision damage, scratch, improper installation and artificial modification damage.

Q7: How to confirm compatibility? A: 1. Verify vehicle configuration via 17-digit VIN code; 2. Check the OE number on the original bladder and confirm the shock cylinder is intact.

5. Customization & Service

• Private Label: Neutral packaging, custom brand logo, product labels, barcodes and OE number printing.
• Packaging Customization: EPE foam protection, color box, export standard carton, custom shipping mark for sea and air freight.
• Bulk Order Support: Spot goods available, competitive wholesale price, price protection for long-term dealers.
• One-stop Supply: Provide front left air spring kit, rear air spring, air compressor, valve block, height sensor, air pipe and sealing accessories.
• Technical Support: Provide installation guidelines, product parameter documents and HD images for cross-border e-commerce.
• Shipping Terms: Spot delivery in 3-7 working days, custom order lead time 7-15 days. Support FOB, CIF, EXW and other international trade terms.

6. Custom Core Attributes

Material: Multi-layer weather-resistant rubber bladder + matching sealing clamps & O-rings

Installation Position: Front Suspension - Right Side (Repair Kit Only, Without Shock Core)

Pressure Resistance: 0-1.4MPa High Pressure Resistant

Service Life: 80,000 KM+ Durability

Features: Air Spring Repair Kit, Reuse Original Shock Cylinder, Leak-proof, Aging-resistant, SUV Air Suspension Parts

Quality Standard: ISO9001 Certified Aftermarket Replacement Quality
