5102.GP 5102.GQ Rear Air Spring Bag For Citroen Jumpy Peugeot Expert Fiat Scudo 2007‑2016

Product Info | OE: 5102.GP (Rear Left) / 5102.GQ (Rear Right)

Product Name: Rear Left & Rear Right Air Spring Bag

Important Note: Complete air spring bag assembly, without shock absorber damper core. Left and right structures are different and non-interchangeable.

1. Product Introduction

OE Number: 5102.GP (Rear Left), 5102.GQ (Rear Right)

Product Type: Air Spring Bag Assembly (without damper core)

Mounting Position: Rear Suspension Left / Rear Suspension Right

Structure: Multi-layer reinforced heavy-duty weather-resistant rubber with integrated original-style high-strength plastic sealing base. Designed for commercial vehicle heavy-load conditions. Replace the original damaged air bag while reusing the original intact damper core. No need to replace the full shock strut assembly. Perfectly compatible with factory automatic air suspension system to restore load leveling and rear height stability.

Core Advantages

Heavy-duty rubber material: Ozone-proof, aging-resistant and stretch-resistant, specially developed for long-term loaded and rough road conditions of commercial vehicles, effectively preventing cracking and slow air leakage.
1:1 OEM precision molding: Exactly the same wave folds, stroke, limit angle and mounting holes for direct bolt-on installation without modification.
100% high-pressure air tightness tested: Every unit passes pressure holding test to ensure zero leakage and stable durability under heavy load.
Cost-effective repair: Only replace the air bag instead of the whole strut to greatly reduce maintenance cost.
Integrated assembly: Complete sealing structure for fast and easy workshop installation without extra accessories.

Common Solvable Faults

Rear body sinking or tilting after parking
Air suspension warning light on dashboard
Frequent air compressor cycling, continuous running and overheating
Severe rear drop under loaded condition and poor driving stability
Air bag aging, cracking, bulging and pinhole slow leakage
Only air bag damaged while damper core is oil-free and intact

Notice: Left and right are non-interchangeable. Full strut replacement is required if damper core is leaking or failed.

2. Fitment

Vehicle Model: Citroen Jumpy / Dispatch, Peugeot Expert, Fiat Scudo

Year Range: 2007‑2016

Fitment: Only for models with factory rear automatic air suspension & load leveling system

Notes:

Not compatible with mechanical coil spring suspension
Strict left/right distinction: 5102.GP (Rear Left), 5102.GQ (Rear Right)
Fit only with intact and oil-free original damper core
VIN verification is highly recommended before ordering

3. Interchangeable OE Numbers

Rear Left Main OE: 5102.GP

Alternative OE: 5102R9, 9663398880, 9676469480

Rear Right Main OE: 5102.GQ

Alternative OE: 5102S0, 9663398980, 9676469280

Remark: All above part numbers are fully interchangeable in aftermarket market.

4. FAQ

Q1: Can left and right air bags be interchanged?

A: No. The limit angle, structure and buckle position are different. Improper installation causes leakage and height error.

Q2: Does it fit mechanical suspension models?

A: No. Only fits factory automatic air suspension models.

Q3: When to replace air bag vs full strut?

A: Replace only the air bag if damper core is intact and oil-free. Replace full assembly if damper is leaking, deformed or failed.

Q4: Need to replace air compressor together?

A: No. Replace only the air bag if compressor works normally. Inspect or replace compressor if overheating or abnormal noise occurs.

Q5: Is calibration required after installation?

A: Yes. Professional diagnostic tool is required for body height calibration and suspension reset to avoid fault codes and height deviation.

Q6: What is the warranty policy?

A: 12-month warranty covers natural aging and air leakage. Excludes collision damage, improper installation and abusive heavy-load usage.

Q7: How to confirm compatibility?

A: 1. Verify configuration via VIN code; 2. Check original OE number; 3. Confirm damper core is oil-free.

5. Customization & Service

Private Label: Neutral packaging, custom logo, labels, barcodes and OE printing.
Packaging Customization: EPE foam, color box, export carton, custom shipping mark for sea & air freight.
Bulk Order Support: Wholesale price, long-term dealer price protection.
One-stop Supply: Full air suspension parts including compressor, valve block, sensor and sealing kits.
Technical Support: Installation docs and HD product images for cross-border e-commerce.
Trade Terms: 3-7 days spot delivery, 7-15 days custom order. Support FOB, CIF, EXW.

6. Custom Core Attributes

Material: Multi-layer heavy-duty weather-resistant rubber + integrated sealing base

Position: Rear Left 5102.GP / Rear Right 5102.GQ (Without Damper Core)

Pressure Resistance: 0-1.4MPa High Pressure Resistant

Service Life: 80,000 KM+

Features: Air Spring Bag, Heavy Load Resistant, Aging Resistant, Leak Proof, Non-interchangeable Left & Right

Quality Standard: ISO9001 Certified Aftermarket Quality
